CAML-TOMLIN FLOW48-2W - Mount Rail Assembly to Fixed Panel

Hold the rail in place behind the fixed panel so that the holes are lined up. Fix the rail to the fixed panel using the rail mount
assembly (6) as shown below. Ensure that the rail is well secured by tightening the bolt using an Allen key.
8. Mount rail assembly to fixed panel
11www.camltomlin.comFLOW INSTALLATION - CORNER
A
A
6
A
