B
2
1. Install the wheel assemblies to the door panel
Set your door panel (2) in the unit and rest it against the wall (this will ease installation in later steps). Ensure that the handle
side of the door panel is located on the proper side (for a left hand door the holes will be located on the left side, for a right
hand door, the holes will be located on the right side). Ensure that the panel is well secured.
Using an Allen key, install the wheel assemblies (7) onto the door panel so that they are facing outwards. Do not install the
wheel covers at this time.
4www.camltomlin.comFLOW INSTALLATION - CORNER
B
A
7
B
x2
