CAML-TOMLIN FLOW48-2W - Assemble Rail Components

Set the wall mount brackets fully onto each end of the rail and fix in place by tightening the inner set screws (see below)
with an Allen key.
The finished (flat) side of the rail should be facing the outside of the shower unit. Ensure that the hole in the rail lines up
roughly with the hole in the fixed panel.
5. Assemble rail components
8www.camltomlin.comFLOW INSTALLATION - CORNER
A
B
A
A
B
B
A
x2
5
4
x2
