CAML-TOMLIN FLOW48-2W - Install Wall Jamb

2. Install wall jamb
On the side where your fixed panel will be mounted, measure 1/2” from the edge of the base and mark a line as shown.
Place the wall jamb (3) against the wall and centre it with the mark on the base. Using a level, adjust the wall jamb until it is
plumb.
Mark the three holes (located inside the wall jamb) onto the wall using a pen or pencil.
5www.camltomlin.comFLOW INSTALLATION - CORNER
B
A
C
A
1/2”
C
x4
3
A
B
C
