MAINTENANCE
Suspension Cables
Inspect condition of Suspension Cables (A). If it
shows abnormal wear or broken strands
anywhere along its length, replace the cables.
Verify that the sleeves (B) are in good condition
and strong. Replace the cables if the sleeves are
defective. Figure 37.
Figure 37
Side Runners
Verify the Side runners (A) mounted on the ski. If
they show flat spots bigger than 1 mm along the
edge, they should be re-sharpened. If the
measurement between the edge of the ski and
the edge of the runner is under 10 mm (13-14
mm when new), the part should be replaced. See
Figure 38.
Figure 38
Carbide Runners
If the ski lacks support through turns on ice, check
condition of carbide runners (A). If carbide inserts
(B) show abnormal wear, cracks or missing
fragments, replace the parts. If the carbide inserts
show flat spots wider than 2 mm, they do not
provide the necessary support. Replace them.
Figure 39.
Figure 39
