15
ADJUSTMENTS
Measure A:
Measure the distance inside the front
Ø202 mm wheels on the front Track Systems.
See figures 21, 22 and 23.
Figure 21
Figure 22 (Distance between front wheels)
Figure 23
Measure B
: Measure the distance inside the rear
Ø202 mm wheels on the front Track Systems. See
figures 24, 25 and 26.
Figure 24
Figure 25 (Distance between rear wheels)
Figure 26
