Application
Protections
Hardware
Records
IRIPRO IRIPRO offers a 3 Phase High X-1ER offers a compact 1 Phase & X-3ER
impedance current differential protection.
These protective relays are numeric relays that provides protection and monitoring with
reliable and fast protection solution in a single unit with programmable digital outputs.
u Measures True RMS with DFT Filter
u CT Inputs
u Bright LCD Display
u 3 Push Button on the Front for HMI
u Front USB Communication
u LEDs for Annunciation
u Single Phase / Three Phase High impedance Current Differential
u In-built Harmonic / Inrush Blocking
No. of Digital Outputs : 3 (DO1, DO2, DO3)
Type of Outputs : Relay
Programmable (DO Assignment) : Yes
Relay Reset Type : Programmable (Auto/Manual)
u Five Fault records with time stamp
Protection Function Description
Relay Latching (86)
Relay can be configured to Latch /Unlatch depending on configuration.
(Latching is possible in presence of Auxiliary supply voltage only)
Reset Delay
This parameter introduces a delay in opening of relay contacts, when the current goes
below the drop out value for current differential. This parameter will not work when manual
reset mode is selected.
Inrush Blocking
Relay is equipped with in-built facility of Inrush blocking to avoid nuisance tripping and
stable operations.
Output Contacts
04
