Candy CCHA 110 - Components

English Components
a
Chest lid
b
Lid seal
c
Interior light
*
d
Storage compartment
e
Separator
*
f
Fast freeze compartment
*
g
Housing
h
Plug (defrost water)
*
i
Control panel
k
Ventilation grid
l
Temperature control
*
Thermostat
m
Fast freeze key
*
yellow
n
Alarm
*
red
o
Power
*
green
p
Condenser
*
*
depending on Model
Control panel versions FIG. 4
Please underline the appropriate version for your appliance
A Temperature control (Thermostat)
B ALARM red light
D FAST FREEZE yellow light
1st VERSION with FAST FREEZE LIGHT SWITCH FIG. 4a
2nd VERSION without FAST FREEZE function FIG. 4b
A Temperature control (Thermostat)
C ALARM red light
If the indicator-lights on your appliance are laid out in a different way, the following always apply:
green = appliance operating; red = ALARM; yellow = FAST FREEZE FUNCTION ON
