EN-18
Technical Specification
Cooking Hob
CDI 30
Cooking Zones
2 Zones
Supply Voltage
220-240V~ 50/60Hz
Installed Electric Power
3500 W
Product Size L×W×H(mm)
288X520X56
Building-in Dimensions A×B (mm)
268X500
Weight and Dimensions are approximate. Because we continually strive to
improve our products we may change specifications and designs without
prior notice.
Installation
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5 cm space shall be
preserved around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select
heat-resistant work surface material to avoid larger deformation caused by
the heat radiation from the hotplate. As shown below:
A (mm) B (mm) C (mm) D (mm) E (mm) F (mm)
268＋4
-0
500＋4
-0
50mini 50 mini 50 mini 50 mini
