Candy CDP 2L949W User Manual

The following things should be checked before starting the dishwasher.
Start of Dishwasher
The content of this manual is very helpful to the users.
After installation, please make sure to keep this manual.
Attention:
1 The dishwasher is level and fixed properly
2 The inlet valve is open
3 Fill hose connections are fully tightened and not leaking
4 The wires are tightly connected
5 The power is switched on
6 The inlet and drain hoses are knotted
7 All packing materials and printings should be taken out from the dishwasher
Extension Hose
If you need a drain hose extension, make sure to use a similar drain hose.
It must be no longer than 4 metres; otherwise the cleaning effect of the dishwasher could be reduced.
Water Outlet
Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
Ensure that the water drain hose is not kinked or squashed.
If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly
into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable
container that is held outside and lower than the sink.
How to Drain Excess Water From Hoses
Syphon Connection
The waste connection must be at a height less than 1000 mm (maximum) from the bottom of the dish.
The water drain hose should be fixed .
17

Candy CDP 2L949W Specifications

General

Door color	White
Control type	Buttons
Product size	Slimline (45 cm)
Built-in display	No
Appliance placement	Freestanding
Upper basket adjustable height	Yes
Cycle time	205 min
Noise level	49 dB
Drying system	Condensation
Delay start (max)	24 h
Dishwashing programs	-
Number of place settings	9 place settings
Number of washing programs	5
Drying class	A
Annual water consumption	2520 L
Annual energy consumption	197 kWh
Current	10 A
AC input voltage	230 V
Water consumption per cycle	9 L
Energy consumption per cycle	0.69 kWh
Package weight	42350 g

Weight and Dimensions

Depth	580 mm
Width	450 mm
Height	820 mm
Weight	38410 g
