1. Remove the kickplate.
2. Turn the locking levers anti-clockwise
and pull out the condenser.
3. Pull out the condenser unit.
4. Gently remove any dust or fluff with a
cloth, then wash the unit by holding it
under a running tap turning it so that
water flows between the plates, to
remove any dust or fluff.
5. Check the gasket position after cleaning.
Fit the gasket into the groove if it is
misaligned.
6. Refit the condenser ensuring it is in the
correct way (as indicated by the arrow)
and pushed firmly into place.
7.
Lock the levers by turning them clockwise.
Be sure that condenser unit fixed to the
basement tightly.
8. Refit the kickplate.
