Cannondale CAAD13 - Technical Frame Specifications

6
137370 Rev 1.
EnglishCAAD13 - Owner’s Manual Supplement
TECHNICAL INFORMATION
Frame Specifications
Item Specification
Headset : Integrated, UPR 11/8 in, LWR 11/4 in
Bottom Bracket: Type/Width BB30A / 73 mm
Front Derailleur Braze-on
Seat Post: Dia./Binder Internal Wedge -
Min. Seat Post Insert
65 mm
Max. Seat Post Insert
44cm-140 mm, 48 cm - 179 mm,
5162 cm (measure)
Tire Size x Max. Width
DISC BRAKES: 700c x 30 mm (measured)
RIM BRAKES: 700c x 28 mm (measured)
Brakes:
Mount Type / Min/Max Rotor Dia. (mm)
DISC: Flat Mount 140 mm, 160 mm
RIM: Direct Mount
Axles:
Type / Hub Spacing / Length (mm)
DISC: Front: Speed Release TA Double
Lead / 100  12/119, Rear: Speed Release TA
Double Lead / 142  12 / 165
RIM: Front: Quick release/ 100  9
Rear: Quick release 130  10
Intended Use:
ASTM Condition 1
Max. Weight Limit: Total
(rider+all equipment)
285 lbs / 129 kg
