01
To ensure proper ventilation and easy operation, set up the machine in an area that meets the
minimum requirements for clearance, as illustrated below.
View from Above
(When the optional Staple Finisher-H1 is attached.)
* The width is 37 1/8" (941 mm) when no options are attached.
Installation Space Requirements
37 3/4" (960 mm)
21 1/4" (540 mm)
50 1/4" (1,276 mm)
*
4" (100 mm)
To Next Page
