Front View
(1) top cover
Open to replace an ink tank or remove jammed paper inside the printer.
(2) paper support
Extend to load paper in the rear tray.
(3) rear tray
Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same
time, and fed automatically one sheet at a time.
Loading Plain Paper / Photo Paper
Loading Envelopes
(4) paper guides
Align with both sides of the paper stack.
(5) front cover
Open to pull out the paper output tray before printing.
(6) paper output tray
Printed paper is ejected. Open it before printing.
41
