Canon EOS REBEL T7I User Manual

74
You can display a grid in the viewfinder to help you check the camera tilt
or compose the shot.
1
Select [Viewfinder display].
 Under the [52] tab, select
[Viewfinder display], then press
<0>.
2
Select [Grid display].
3
Select [Show].
 When you exit the menu, the grid will
appear in the viewfinder.
3 Displaying the Grid
You can display a grid on the LCD monitor during Live View shooting and
before you start shooting a movie (p.243, 305).

Canon EOS REBEL T7I Specifications

General

Sensor	24.2MP APS-C CMOS
Image Processor	DIGIC 7
ISO Range	100-25600 (Expandable to 51200)
Autofocus Points	45-point all cross-type
Video Recording	Full HD 1080p at 60 fps
Connectivity	Wi-Fi, NFC, Bluetooth
Dimensions	131.0 x 99.9 x 76.2 mm
Camera Type	DSLR
Continuous Shooting	Up to 6 fps
Battery	LP-E17
Viewfinder	Optical Pentamirror
LCD Screen	3.0-inch Vari-angle Touchscreen
Battery Life	Approx. 600 shots
Weight	532g (body only)
