Canon imageCLASS LBP623Cdw - Page 7

Fordetails
"Setting Up Using the Setup Guide" in the User's Guide
3.
TakenoteoftheSSIDandnetworkkey.
•Checkthelabelontherouter.
User's Guide
•Thesettingoperationiseasieriftherouteris
provided with a WPS mark.
User's Guide
4.
Set the access point and network key
according to the screen below.
OK
For more
information, refer
to the manual.
1. Select <OK>.
2. Select <SSIDSettings>.
3. Select <Select Access Point>.
4. Selecttheaccesspoint(SSID).
5. EnteraWEPkey(networkkey),andselect
<Apply>.
6. Select<Yes>.
•Waituntilmessage<Connected.>isdisplayed.
7. Select<Close>.
•TheIPaddresswillbeautomatically
configured in a few minutes.
5.
Install the driver and software.
P.8 "Installing the software"
Now you are finished with the
configuration of the initial settings.
To connect via wired LAN
The machine does not come with a LAN cable.
Please have one ready, if necessary.
1.
Make sure that the computer is connected to a
router properly.
2.
Check the network settings on the computer.
3.
Connect the LAN cable.
•Afterconnectingthecable,waitafewminutes
(untiltheIPaddressissetautomatically).
•IfastaticIPaddresshasbeensetonthe
computer, set the machine's IP address
manually.
4.
Install the driver and software.
P.8 "Installing the software"
Now you are finished with the
configuration of the initial settings.
7
Quick Setup
En
