20
If you push the Carriage to the left edge, the blade of the Cutter Unit will be lowered in preparation to
cut the paper. Be careful not to pinch your fi ngers between the Carriage and Platen if you have pushed
the Carriage to the left edge or if a paper jam occurs during cutting.
•
1
2
3
4
5
If roll paper jams, follow the steps below to remove jams.
Turn the printer off.
(→"Turning the Printer On and Off," User Manual)
Open the Top Cover .
If Roll Paper Jams
Clear jammed roll paper as follows.
If the Carriage is out, move the Carriage out of the way,
away from the paper.
Lift the Release Lever .
Holding the paper on both sides, pull the jammed portion
out toward the front. Use scissors or a cutting tool to cut
away the printed or wrinkled portion.
To Next Page
