Canon imagePROGRAF TM-200 Service Guide

Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 10
Table 12 - imagePROGRAF TM-200 Box Contents
• imagePROGRAF TM-200 Printer
• Stand / Basket (imagePROGRAF TM-200 Printer with stand only)
• 2”/3” Core Media Spool (Adaptors Included)
• US AC Power Cable
• Tools and Screws
• Print Head PF-06
• Maintenance Cartridge (Installed)
• 5 Ink Tanks (130 ml: MBK, 90ml: C/M/Y/BK)
• Sample Heavyweight Coated Paper (A2/5 Sheets)
• Ethernet Card (built-in)
• USB 2.0 High-speed Interface
• USB Connection Sheet
• iWR Service Terms Leaflet
• User Manual
• Quick Setup Guide
• User Software CD for Windows (Printer Driver Utilities)
• PosterArtist Lite CD
• User Registration Card
Table 13 - imagePROGRAF TM-200 MFP L24ei Box Contents
(Ships on two pallets)
• Colortrac scanner
• Colortrac L24ei scanner
• Printer mounting brackets, fixings & 3mm tool
• Document return guides
• Calibration target
• CD for Lei Scan App software (includes PDF documentation: Lei Scanner Guide and Lei
Icon Guide per language)
• Lei Scanner Guide (includes Assembly Guide, User Guide & Quick Start Guide).
• Ethernet cable (2 meter)
• Power Supply
• Feet for desktop use
• Paper edge guides and paper refeed preventers
• imagePROGRAF Printer
• imagePROGRAF TM-200 Printer
• Stand / Basket
• 2”/3” Core Media Spool (Adaptors Included)
• US AC Power Cable
• Tools and Screws
• Print Head PF-06
• Maintenance Cartridge (Installed)
• 5 Ink Tanks (130 ml: MBK, 90ml: C/M/Y/BK)
• Sample Heavyweight Coated Paper (A2/5 Sheets)
• Ethernet Card (built-in)
• USB 2.0 High-speed Interface
• USB Connection Sheet
• iWR Service Terms Leaflet
• User Manual
• Quick Setup Guide
• User Software CD for Windows (Printer Driver Utilities)
• PosterArtist Lite CD
• User Registration Card

Canon imagePROGRAF TM-200 Specifications

General

Max Print Resolution	2400 x 1200 dpi
Max Media Width	24 inches
Connectivity	USB, Ethernet, Wi-Fi
Printer Type	Large Format Printer
Media Thickness	0.07 - 0.8 mm
Memory	2 GB
Operating System	Windows, Mac OS
Power Supply	AC 100-240 V, 50/60 Hz
Print Technology	Inkjet
Number of Ink Colors	5
Ink Types	Pigment-based
Media Handling	Roll Feed
Nozzle Pitch	1200 dpi
Ink Droplet Size	5 picoliters
Media Width	203.2 - 610 mm
Maximum Roll Outer Diameter	150 mm
Media Core Size	2 inches
Printing Speed (Plain Paper)	24 sec/A1
Interface	USB 2.0, Wi-Fi
Acoustic Noise	44 dB
