Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 11
II. Hardware Solutions
A. Basket
The Basket can store multiple sheets. There are three position settings:
• Regular position - Holds up to 1 A0 or A1 portrait sheets
• Extended position A (Drape) - Holds up to 20 A0 or A1 portrait sheets face
down
• Extended position B (Stack) - Holds up to 20 A0 or A1 landscape sheets
face down. (Only available on the imagePROGRAF TM-305)
B. Z36 Scanner Features
The Z36 Scanner is a 36-inch scanner for the imagePROGRAF
TM-305/TM-300 printer.
1. Printer Mounting
The Z36 Scanner stand is mounted directly to the imagePROGRAF
TM-305/TM-300 printer. With the scanner mounted the main paper roll is
accessible by lifting the scanner on its hinged shelf. The ink tanks are
accessible when scanner is down.
2. Z36 All-In-One Controller
• The Z36 All-In-One (AIO) Controller is a combination desktop computer
and monitor.
• Operating System: Windows 10 Enterprise LTSC 64 bit
• The Z36 All-In-One Controller is preinstalled with the following software
solutions to manage print processes:
• SmartWorks MFP Software Version 6.0
• imagePROGRAF Status Monitor
3. Copy
Scanned images can be printed (once or multiple times) to the connected
imagePROGRAF TX Series printer.
4. Scan to PC
Using SmartWorks MFP Software Version 6.0 the Z36 scanner can scan
images to the Z36 All-In-One Controller.
Scan to PC supports multiple file types (PDF, Multi Page PDF, JPEG, TIFF,
PDF/A, DWF).
5. Scan to USB Memory
Using SmartWorks MFP Software Version 5.0 the Z36 scanner can scan
images to USB memory. Scan to USB Memory supports multiple file types
(PDF, Multi Page PDF, JPEG, TIFF, PDF/A, DWF).
