Canon imagePROGRAF TM-200 Service Guide

Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 30
Table 28 - imagePROGRAF TM-200 Consumable Parts List
Unit Description
Counter
Name
Part Number
2
Estimated Life
15
(A1 Size)
Carriage
Carriage unit
CR1
QM4-6733-000
30,000 sheets
Carriage unit
CR2
QM4-6733-000
Linear Scale
QC4-9427-000
Carriage unit
CR3
QM4-6733-000
85,000 sheets
Ink supply
Ink tube unit
CR4
QM4-5862-000
38,000 sheets
Multi sensor Multi sensor unit CR5 QM4-5977-000 30,000 sheets
Purge Purge unit
PG1
QM4-6171-000 50,000 sheets
PG2
PG3
Non-ejection
detection
Head management sensor unit Hma1 QM4-6180-000 123,000 sheets
Carriage motor DC motor MT1 QK1-5068-000 200,000 sheets
LF encoder
sensor
Paper feed encoder unit
LFS1
QM4-6205-000
25,000 sheets
Film, timing slit disk
QD1-2702-000
Mist collection
Exhaust mist duct unit
Mi1
QM4-5995-000
30,000 sheets
Waste ink
Waste ink box unit, HP
Wia1
QM4-4241-000
25,000 sheets
Waste ink box unit, Center
Wia5
QM4-4242-000
Platen fan unit Wia7 QM4-5861-000 103,000 sheets
2 Part numbers are subject to change without notice.
15 Based on Heavyweight Coated Paper HG 145 g/m
2
, Photo illustration, standard mode, Image Duty:
12.5% × 3 color (CMY) + 6.8% (MBK) + 5.7% (BK) = 50% Duty. The estimated life is subject to
change depending upon many factors including, without limitation the print mode, operating
condition, type of image printed and customer handling of the equipment.

Canon imagePROGRAF TM-200 Specifications

General

Max Print Resolution	2400 x 1200 dpi
Max Media Width	24 inches
Connectivity	USB, Ethernet, Wi-Fi
Printer Type	Large Format Printer
Media Thickness	0.07 - 0.8 mm
Memory	2 GB
Operating System	Windows, Mac OS
Power Supply	AC 100-240 V, 50/60 Hz
Print Technology	Inkjet
Number of Ink Colors	5
Ink Types	Pigment-based
Media Handling	Roll Feed
Nozzle Pitch	1200 dpi
Ink Droplet Size	5 picoliters
Media Width	203.2 - 610 mm
Maximum Roll Outer Diameter	150 mm
Media Core Size	2 inches
Printing Speed (Plain Paper)	24 sec/A1
Interface	USB 2.0, Wi-Fi
Acoustic Noise	44 dB
