Canon imagePROGRAF TM-200 Service Guide

Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 2
• Direct Printing from USB memory is supported.
• Gigabit Ethernet support for 10Base-T, 100Base-TX, and 1000Base-T.
• Wireless LAN support for IEEE802.11n, IEEE802.11g and IEEE802.11b.
• The imagePROGRAF TM-Series uses the LUCIA TD pigment ink. The
LUCIA TD pigment ink produces high-precision drawings with fine lines
and sharp text. Additionally, the LUCIA TD ink system provides longer
lasting prints in weather resistance and storage.
• imagePROGRAF TM-Series printer ink tanks are available in 300 ml and
130 ml capacity to suit the user’s printing volume, the printing environment
and other conditions.
• Sub tanks mounted at each ink port allow end-users to replace the ink tank
during a print job.
• Borderless printing is supported.
• Compatibility with imageWARE Remote allows centralized management of
customers' printer information.

Canon imagePROGRAF TM-200 Specifications

General

Max Print Resolution	2400 x 1200 dpi
Max Media Width	24 inches
Connectivity	USB, Ethernet, Wi-Fi
Printer Type	Large Format Printer
Media Thickness	0.07 - 0.8 mm
Memory	2 GB
Operating System	Windows, Mac OS
Power Supply	AC 100-240 V, 50/60 Hz
Print Technology	Inkjet
Number of Ink Colors	5
Ink Types	Pigment-based
Media Handling	Roll Feed
Nozzle Pitch	1200 dpi
Ink Droplet Size	5 picoliters
Media Width	203.2 - 610 mm
Maximum Roll Outer Diameter	150 mm
Media Core Size	2 inches
Printing Speed (Plain Paper)	24 sec/A1
Interface	USB 2.0, Wi-Fi
Acoustic Noise	44 dB
