3
Confirming the Installation Space
When installing the printer, it is recommended that you secure the following space around the printer.
Important
●
The printer stand may not be included with your model.
●
The space required in front of the printer differs depending on how the basket supplied with the printer stand is used.
TM-355/TM-350
Required space (W x D x H)
When using SD-35: 66.4 x 66.9 x 65.6 inches (1,685 x 1,698 x 1,664 mm)
When using SD-34: 66.4 x 57.8 x 65.6 inches (1,685 x 1,468 x 1,664 mm)
0.4 inches
(10 mm)
7.9 inches
(200 mm)
23.7 inches
(600 mm)
7.9 inches
(200 mm)
23.7 inches (600 mm)
TM-340
Required space (W x D x H)
When using SD-33: 66.4 x 57.8 x 65.6 inches (1,685 x 1,468 x 1,664 mm)
7.9 inches
(200 mm)
23.7 inches
(600 mm)
7.9 inches
(200 mm)
23.7 inches (600 mm)
ENGLISH
To Next Page
