Canon imagePROGRAF TM-305 Service Guide

Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 40
Table 33 – Z36 Scanner Specifications
Item
Specification
Printers Supported
imagePROGRAF TZ-30000
imagePROGRAF TX-4100
imagePROGRAF TX-3100
imagePROGRAF TM-305
imagePROGRAF TM-300
Scan width
Approximately 36" (914mm)
Paper path width
Approximately 38" (965mm)
Minimum scan width
Approximately 6" (150mm)
Maximum scan length
JPEG/PDF - Approximately 315“ (8m)
TIFF - Approximately 598.4” (15.2m)
Minimum scan length
Approximately 3.2" (8cm)
Document thickness (1)
0.003” – 0.04” (0.07 – 1.0mm)
Scanner size. W x H x D
(Document Return Guides, paper tray down)
Approximately 41.6 x 6.1 x 9.9 inches
(1,056 x 156 x 251 mm)
Scanner Weight
Approximately 17lbs 3oz (7.8Kg)
Scanner Operating Environment
Temp: 10-35C Humidity: 10-90%
Imaging technology (2)
SingleSensor
(Full width straight-line CIS; Colortrac patent).
Optical Resolution (dpi)
Up to 1,200dpi
Color depth and space
16.7 million color RGB (24-bit), sRGB. 256 level
greyscale (8-bit). Black & White (1-bit)
Illumination
Full width dual LED illumination
96 LEDs
Scanner optics & calibration
Chemically hardened, scratch resistant scan glass
Document handling
Face up
Rear exit (Document Return Guides to return
document to front)
Flat Paper path
Viscous damped document hold up system
High Precision Motor
Silicone rubber document feed system
Scan speed (3)
13ips (inches per second)
8-bit grayscale & mono @200dpi
Scan to PC: Scan speed (3)
3ips
24-bit color @200dpi
Copy: Scan speed (3)
6ips
24-bit color @200dpi
Scan Accuracy
+/-0.1% +/-1 pixel (Scan accuracy may vary
depending on the operating environment and
the type & thickness of media).
Interface USB
3.0 (backward compatible to USB2)
Scanner controls
Stop, Advance, Rewind, LED status

Canon imagePROGRAF TM-305 Specifications

General

Max Print Resolution	2400 x 1200 dpi
Connectivity	USB, Ethernet, Wi-Fi
Printer Type	Large Format Printer
Ink Droplet Size	5 picoliters
Memory	2 GB
Operating System	Windows, Mac OS
Power Supply	AC 100-240V, 50/60Hz
Number of Ink Colors	5
Media Handling	Roll feed
Max Media Width	36 inches
Hard Drive	500 GB
Number of Nozzles	15, 360
Nozzle Pitch	1200 dpi
Ink Tank Capacity	130 ml per color
Media Thickness	0.07 to 0.8 mm
Media Core Size	2 inches
Media Sizes	A4, A3, A2, A1, A0
Media Types	Plain Paper, Coated Paper, Glossy Photo Paper, Satin Photo Paper
Ink Type	Pigment ink
