Canon imagePROGRAF TM-Series Service Guide
imagePROGRAF TM-Series Service Guide June 2021
Revision 4 Page 1
I. Product Overview
A. Overview
The Canon imagePROGRAF TM-305 and imagePROGRAF TM300 are 36-
inch large format printers. The Canon imagePROGRAF TM-200 is a 24-inch
large format printer. These printers are designed for the low volume and mid
volume CAD market.
The imagePROGRAF TM-305 MFP Z36 and imagePROGRAF TM-300 MFP
Z36 are 36-inch are large format multi-function print solutions equipped with
the Colortrac Z36 Scanner system.
The Canon imagePROGRAF TM-Series (imagePROGRAF TM-305,
imagePROGRAF TM-300, imagePROGRAF TM-200, imagePROGRAF TM-
305 MFP Z36, and imagePROGRAF TM-300 MFP Z36) bring the following
capabilities to end-users:
The imagePROGRAF TM-305/TM-300 printer includes a single roll paper
feed, a stand and a basket that stores up to 20-sheets in Extended Position
A (Drape) (imagePROGRAF TM-305/TM-300) and up to 20-sheets in
Extended Position B (Stack) (imagePROGRAF TM-305 Only).
The imagePROGRAF TM-200 includes a single roll paper feed. The
imagePROGRAF TM-200 is available without a stand and basket or can
be configured with stand and a basket that stores up to 20-sheets in
Extended position A.
The imagePROGRAF TM-Series supports prints up to 2,400 x 1,200 dpi
resolution at a high speed
1
.
The imagePROGRAF TM-Series is equipped with the PF-06 Printhead.
The PF-06 Printhead uses 2,560 nozzles per color (total 15,360) to achieve
up to 2400 x 1200 dpi images. The superfine 5pl droplet per color produces
delicate color gradations and high-definition.
The L-COA PRO high-speed image-processing engine combines a color
conversion system that uses image-processing algorithms to generate
ideal ink combinations with a multi-core ASIC (Application-Specific
Integrated Circuit) processor.
The
The imagePROGRAF TM-305 MFP Z36, and imagePROGRAF TM-300
MFP Z36 include the Z36 Scanner mounted directly to the
imagePROGRAF TM-305/TM-300 printer. The Z36 Scanner has an optical
resolution of up to 1,200 dpi and has a smaller footprint when compared to
the T36 Scanner.
The imagePROGRAF TM-300 MFP L36ei and imagePROGRAF TM-200
L24ei include a scanner that has an optical resolution of up to 600 dpi.
1
Refer to the Service Manual for the print speed and resolution variations.
