CAUTION:
When changing this switch, make sure to turn OFF and then ON then ON the power supply twice. This is the specification
for changing the fax configuration and is the same specification as adding the Fax Board to the existing machine.
Details of Bit 4
This is the switch to set to display the send job stop confirmation screen if the Stop key is pressed during sending fax.
0: No
1: Yes
Details of Bit 5
This is the switch to set to stop the ongoing send job or incomplete send job if the Stop key is pressed during sending fax.
0: Incomplete send job
1: Ongoing send job
Setting of Menu Switch (MENU)
■ Configuration of Menu Switches
<1/3> <READY>
ReportSssw
Menu Num Ncu Type
IPFAX Print Clear Test
OK
001
002
003
004
005
006
007
008
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
←㸦yyyyy㸧{aaaaa㹼bbbbb}
No. Function Scope of selection
005 NL equalizer 1: ON, 0: OFF
006 Phone line monitoring 0 to 3
007 Transmission level (ATT) 8 to 15 (ex: 15 = -15 dBm)
008 Upper limit for V.34 modulation speed 0: 3429, 1: 3200, 2: 3000, 3: 2800, 4: 2743,
5: 2400
009 Upper limit for V.34 data speed 0 to 13
010 Frequency of pseudo CI signal 0: 50 Hz, 1: 25 Hz, 2: 17 Hz
005: NL equalizer
Select ON/OFF of NL equalizer.
Select "1: ON" in the case of frequent errors caused by line status at the time of communication.
NOTE:
Error codes caused by line status at the time of transmission
##100, ##101, ##102, ##104, ##201, ##281, ##282, ##283, ##750, ##755, ##765, ##774, ##779, ##784, ##789
Error codes caused by line status at the time of reception
##103, ##107, ##114, ##201, ##790, ##793
006: Phone line monitoring
Set whether to make monitoring tone of the phone line from the speaker.
• 0 (DIAL):
To make monitoring tone of the phone line from the speaker from the start of line connection until the DIS.
8. Service Mode
568
