53 Routine Maintenance 3
Replacing the Stamp Cartridge (Duplex Color Image
Reader Unit-G1) (Optional)
Originals sent via the Duplex Color Image Reader
Unit-G1 can be stamped to indicate that they have
been sent. Replace the stamp cartridge when the
stamp mark is faint or no longer visible.
IMPORTANT
When replacing the stamp cartridge, take care not
to allow ink to come into contact with your hands or
clothing. If ink gets onto your hands or clothing, wash it
o immediately with cold water.
NOTE
The Duplex Color Image Reader Unit-G1 is an optional
product.
1
Open the feeder, and open the document
scan cover.
1. Open the feeder.
2. Pull the lever above the feeder, and open the document
scan cover.
IMPORTANT
Open the document scan cover carefully, as not to scratch
the platen glass.
2
Open the stamp cover.
3
Insert the stamp cartridge.
1. Remove the old stamp cartridge, using tweezers.
2. Push in the new stamp cartridge until it clicks.
IMPORTANT
• Insert the stamp cartridge so that it is not slanted.
• Insert the stamp cartridge properly, or paper jams may
occur.
4
Close the stamp cover.
When closing the cover, be careful not to get your
ngers caught, as this may result in personal injury.
5
Close the document scan cover, and the
feeder.
1. Close the document scan cover.
2. Close the feeder.
• When closing the document scan cover and the
feeder, be careful not to get your ngers caught, as
this may result in personal injury.
• Be aware that the light emitted from the platen
glass may be very bright when closing the feeder.
To Next Page
