Points to Note on Disassembly and Reassembly
1 Note on locations prohibited from disassembly
mblies that are prohibited from disassembly and their adjustment outside the factory cannot be conducte
ndicated by red screws.
t never loosen or remove the red screw, because normal operation and print can't be done if it is loosene
moved.
F-4-2
4.3.2 Moving the carriage manually
Move the carriage as required during disassembly/reassembly to prevent the carriage form contacting the parts
to be removed.
The carriage does not move when capped. When uncapping moving the carriage, refer to the procedures in
DISASSEMBLY/REASSEMBLY>Points to Note on Disassembly and Reassembly>Opening the Cap/Moving
the Wiper Unit.
