Chapter
4-1
4.1 Service Parts
4.1.1 Service Parts
The service parts indicated below require careful handling.
1. Keep all packages with the warning not to turn over.
Pay careful attention to all individually packaged service part (carriage unit, purge unit, ink tank unit, and o
parts) boxes marked "This side up" and handle appropriately.
F-4-1
.2 Disassembly/Reassembly
.2.1 Disassembly/Reassembly
or the procedure for disassembly/reassembly of the components excluding the major components,refer to the
aets catalog.
lustrations in the parts catalog are assigned illustration nombers according to the order in which parts are
sassembled.
