Canon iR6000 Service Manual

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 3 STANDARDS AND ADJUSTMENTS
3-46 T
Sensor Connector No. Checks I/O Voltage
I/O address display display
PS38 D>J107-B16 Put paper over the point of Paper Present 1 5V
Reversal sensor 2 IO-P02-7 detection. Absent 0 0V
PS45 D>J106-B5 Put paper over the Web Present 0 0V
Fixing web length sensor IO-P02-12 sensor. Short 1 5V
PS46 D>J106-B2 Put paper over the point of Paper Present 1 5V
Delivery assembly jam sensor IO-P06-2 detection. Absent 0 0V
PS47 D>J115-B2 Remove the deck from the machine, Light-blocking Present 1 5V
Right deck level (upper) sensor IO-P05-8 and move the sensor lever. plate Absent 0 0V
PS48 D>J115-B5 Remove the deck from the machine, Light-blocking Present 1 5V
Right deck level (lower) sensor IO-P05-12 and move the sensor lever. plate Absent 0 0V
PS49 D>J115-B8 Remove the deck from the machine, Light-blocking Present 1 5V
Left deck level (upper) sensor IO-P05-9 and move the sensor lever. plate Absent 0 0V
PS50 D>J115-B11
Remove the deck from the machine, Light-blocking Present 0 0V
Left deck level (lower) sensor IO-P05-13 and move the sensor lever. plate Absent 1 5V
T03-1003-04
Download Free Service Manual at http://printer1.blogspot.com

Canon iR6000 Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan
Print Speed	60 ppm
Duplex Printing	Yes
Network Connectivity	Ethernet
Paper Sizes	A3, A4, B4, B5
Warm-Up Time	30 seconds
Multiple Copies	Up to 999
Magnification	25-400%
Copy Speed	60 ppm (A4)
