8-7
Maintenance
8
6 Hold the cartridge and align the projections (A) on both sides of the cartridge to the guides (B) in the
machine, then gently slide the cartridge into the machine as far as it will go.
Be sure to position the arrow mark (C) on the cartridge towards the inside of the machine.
7 Close the front cover.
NOTE
If the LCD displays <INSTALL CARTRIDGE>, reset the machine by opening the front cover and then closing it.
C
B
A
A
B
B
