Additional
Information
77
E
Specifications
OPTURA
Power Supply (rated): 7.2 V DC
Power Consumption (while
recording with the AF turned on):
7.1 W
Television system:
EIS standard (525 lines, 60 fields)
NTSC color signal
Video recording system:
2 rotary heads, helical scanning
DV system (Consumer digital VCR
SD system)
Digital component recording
Audio recording system: PCM digital
sound: 16 bit (48kHz/2ch),
12 bit (32kHz/4ch)
Image sensor: 1/3” Progressive Scan
CCD (charge coupled device)
380,000 pixels (360,000 effective
pixels)
Tape format: Videocassettes bearing
the mark.
Tape speed:
SP:
3
/4 ips (18.81 mm/s);
LP:
1
/2 ips(12.56 mm/s)
Maximum recording time:
SP: 60 minutes (with a 60 min.
cassette);
LP: 90 minutes (with a 60 min.
cassette)
Fast forward/rewind time:
Approx. 2 min. 50 sec. (with a
60 min. cassette)
Lens: F/1.8–3.2, 14× power zoom,
5.2–72.8mm
Focusing system: TTL autofocus,
manual focusing possible
Minimum focusing distance:
3
/8 inch
(1 cm) on maximum wide angle
Maximum shutter speed:
1/2,000 sec
Minimum illumination: 2.5 lx (using
the slow shutter at
1
/8 sec)
Recommended illumination:
More than 100 lx
Filter diameter: 49mm
Viewfinder: 0.55-inch, color LCD
(approx. 113,000 pixels)
LCD screen: 2 in measured diagonally
(5.1 cm), 113,000 pixels (approx.)
Microphone: Stereo electret condenser
microphone
DV Terminal: Special 4-pin connector
(conforms to IEEE1394)
Output level:
Video terminal: 1 Vp-p/75 ohms
unbalanced
S-video terminal: 1 Vp-p (Y signal),
0.286 Vp-p (C signal)
Audio terminal: –10dBV, less than 3
kohms, unbalanced
Operating temperature range:
32–104 °F (0–40 °C)
Dimensions: 5
7
/16 × 4
3
/16 × 5
1
/4 in
(138 × 106 × 133mm)
Weight: 2lbs approx. (930g)
Battery type: Rechargeable lithium
ion battery
Rated voltage: 7.2 V DC
Operating temperature: 32°–104°F
(0°–40°C)
Battery capacity: 1,350 mAh
Dimensions: 1
1
/2 ×
13
/16 × 2
13
/16 in
(38.2 × 20.5 × 70.5 mm)
Weight: 3
3
/8 oz (96 g)
Weight and dimensions are approximate
Errors and omissions excepted.
Subject to change without notice.
Canon is a trademark of Canon Inc.
