Canon PC921 - Variable Resistors (VR) and Check Pins by PCB; DC Controller Pcb; Composite Power Supply Pcb

CHAPTER 3 ARRANGEMENT AND FUNCTIONS OF ELECTRICAL PARTS
3-6
F. Variable Resistors (VR) and Check Pins by PCB
Of the variable resistors (VR) and check pins, those needed in the field are discussed herein.
Those not found in the discussions are for the factory only, requiring special tools and adjustment
to an extremely accuracy. Do not touch them in the field.
Caution:
VRs that may be used in the field ................
VRs that must not be used in the field .........
1. DC Controller PCB
Figure 3-6
2. Composite Power Supply PCB
Figure 3-7
