CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-37
C. Electrical
1. After Replacing the Major Parts
*1: If you have replaced the composite power supply PCB, check copy images using the Test
Sheet; if (and only if) an image fault is found, adjust the intensity of the scanning lamp and
execute AE adjustment.
Table 2-6
Adjustment
1. Intensity of the scanning lamp
2. AE mechanism
1. AE mechanism
(1. Intensity of the scanning lamp)
(2. AE mechanism)
1. Intensity of the scanning lamp
2. AE mechanism
3. Leading edge non-image width
4. Image leading edge margin
5. Reproduction ratio (fine adjustment)
1. Excute original leading edge stop position ad-
justment
Parts
Scanning lamp
AE sensor PCB
Composite power supply
PCB
*1
DC controller PCB
ADF controller PCB
