Canon PIXMA MX310 - #1 BIT SWITCH

NU
MERIC PARAM. menu
Note: Not used in servicing.
PTT PARAMETER
#3 FAX TYPE
PTT PARAMETER
#4 NCU
Note: Not used in servicing.
Note: Not used in servicing.
PTT PARAMETER
#5 PTT SPECIAL
Note: Not used in servicing.
PTT PARAMETER
#6 FAX TEST
4. Press the OK button after “#1 BIT SWITCH” or “#2 NUMERIC PARAM.” is displayed to enter
each mode.
2-2-3) #1 BIT SWITCH
1. After entering the #1 BIT SWITCH menu, the following screen will be displayed.
#1 BIT SWITCH
SW#01 00000000
2. Each time the OK button is pressed, the SW# is changed from 01 to 20.
Be careful not to enter the SW numbers which are not used in servicing.
The SW numbers which are used in servicing: SW#01, 02, 03, 04, 05, 06, 07, 10, 11, 13
The SW numbers which are not used in servicing (as of August 2007): SW#08, 09, 12, 14-20
3. Since each SW# has 8bit information, use the right or left arrow key to move the cursor to the bit
to be specified and enter the setting value (1 or 0).
Bit7 -> 00000000 <- bit0
After entering the setting value (1 or 0), press the OK button to finalize it.
See the G3 Facsimile Service Data Service Handbook for the definition and description of each
bit of the SW#.
(18/32)
