Canon PowerShot SX620 HS Getting Started

3
Initial Preparations
Initial Preparations
1 Attach the strap.
 Thread the end of the strap through the
strap mount (1), and then pull the other
end of the strap through the loop on the
threaded end (2).
2 Insert the battery pack.
 After aligning the marks on the battery
pack and charger, insert the battery pack
by pushing it in (1) and down (2).
3 Charge the battery pack.
 Plug the power cord into the charger,
then plug the other end into a power outlet.
 The charging lamp turns orange,
and charging begins.
 When charging is fi nished, the lamp
turns green, and you can remove the
battery pack.
 For details on charging time and the
number of shots or recording time
available with a fully charged battery
pack, refer to “Specifi cations” in the
downloadable Camera User Guide.
4 Open the cover.
 Slide the switch (1) and open the cover (2).
(1)
(2)
(
1
)
(
2
)
(
2
)
(
1
)

Canon PowerShot SX620 HS Specifications

General

Megapixel	20.2 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	21.1 MP
Image sensor size	1/2.3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Still image resolution(s)	5184 x 2912, 3648 x 2048, 1920 x 1080, 640 x 360, 5184 x 3456, 3648 x 2432, 2048 x 1368, 640 x 424, 5184 x 3888, 3648 x 2736, 2048 x 1536, 2592 x 1944, 640 x 480, 3888 x 3888, 2736 x 2736, 1536 x 1536, 480 x 480
Scene modes	Fireworks, Night, Portrait, Twilight
Image editing	Crop, Resizing
Photo effects	Black&White, Neutral, Positive film, Sepia, Skin tones, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Fluorescent H, Tungsten
Playback modes	Playlist, Rotation, Shuffle, Slideshow
Shooting modes	Auto, Scene
Camera playback	Highlights
GPS (satellite)	No
Image processor	DIGIC 4+
Self-timer delay	2, 10 s
Languages support	Multi
Camera file system	DCF, DPOF 1.1, Exif 2.3, RAW
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8.1
Power source type	Battery
Battery life (CIPA standard)	295 shots
Digital zoom	4 x
Optical zoom	25 x
Combined zoom	100 x
Focal length range	4.5 - 112.5 mm
Maximum aperture number	6.6
Minimum aperture number	3.2
Number of aspheric elements	2
Lens structure (elements/groups)	13/10
Maximum focal length (35mm film equiv)	625 mm
Minimum focal length (35mm film equiv)	25 mm
Product color	White
Focus	TTL
Focus adjustment	Auto
Auto Focus (AF) points	9
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Macro focusing range (wide)	0.01 - 0.5 m
Normal focusing range (tele)	1 - ∞ m
Normal focusing range (wide)	0.05 - ∞ m
Auto Mode focusing range (wide)	0.01 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, Auto
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Flash off, Flash on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2 m
Flash range (wide)	0.5 - 4 m
Bundled software	CameraWindow DC Map Utility Image Transfer Utility
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVC, H.264, MP4, MPEG4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps
Audio formats supported	AAC
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	4:3
Display resolution (numeric)	922000 pixels
USB version	2.0
USB connector	Micro-USB B
HDMI connector type	Micro

Weight and Dimensions

Depth	27.9 mm
Width	96.9 mm
Height	56.9 mm
Weight	158 g
Weight (including battery)	182 g
