Canon S6300 - Adjustments and Settings after Disassembly and Reassembly; Adjustments

3.4 Adjustments and Settings After Disassembly and Reassembly
3.4.1 Adjustments
(1) User Level
(2) Serviceman Level
2-19
S6300
Part 2: Troubleshooting
Troubleshooting
Timing
After BJ cartridge
replacement
Adjustment
Print head printing position
adjustment
Time Required
10 min.
Tools Required
2 sheets of A4-size
paper
Timing
After control board
replacement or
waste-ink absorber
replacement
After replacement/
disassembly of
carriage unit parts
Insufficient grease
Adjustment
EEPROM setting
Print head printing position
adjustment (including
seam adjustment)
Apply sufficient grease. See
page 2-20
Time Required
2 min.
10 min.
---
Tools Required
None
2 sheets of A4-size
paper
Grease PG-641, FLOIL
KG107A, brush
