Canon SELPHY CP760 User Manual

5
2. Checking and Changing the Total Number of Printed Sheets
For SELPHY CP770, the total number of printed sheets can be checked and changed by using the soft-
ware for checking and changing the total number of printed sheets. Perform this operation if the total
number of printed sheets needs to be changed when repairs are made.
2.1 Required Equipment
1 Computer on which the printer driver for SELPHY CP770 is installed
(Supported OSes: Windows 2000 and Windows XP)
2 USB cable (Commercially available)
3 Software for checking and changing the total number of printed sheets for SELPHY CP770 “CP770
Sheets Printed Change Software” (Download from SSIS)
2.2 Procedure for Checking and Changing
(1) Connect the SELPHY CP770 and the computer with the USB cable, and turn on the power to the
SELPHY CP770.
Double-click on CP770FVC.exe to start the software.
When the dialog box below appears, click the [Start] button.
(2) The total number of printed sheets is displayed in the dialog box below.
Check the total number of printed sheets. To leave the number unchanged, click the [Exit] button to
exit the software.
To change the number, click the [Overwrite] button.

Canon SELPHY CP760 Specifications

General

Print technology	Dye-sublimation
Maximum resolution	300 x 300 DPI
Credit card	Yes
Standard media sizes	148 x 100mm - [KP-36IP, KP-72IP, KP-108IP] 100 x 200mm - [KW-24IP] 119 x 89mm - [KL-36IP] 86 x 54mm - [KC-18IF] 22.0 x 17.3mm (x8) - [KC-18IL]
Paper tray media types	Photo paper
Non-ISO print media sizes	l
Dimensions (WxDxH)	180 x 126.7 x 73.1 mm
Connectivity technology	Wired
Compatible operating systems	Windows 2000 SP4 / XP (SP2) / Vista Mac OS X v10.3 - v10.4
USB 2.0 ports quantity	1
Compatible memory cards	CF, microSDHC, miniSD, MMC, MMCmicro, MS DUO, MS PRO, MS PRO DUO, SD, SDHC, xD
Power consumption (printing)	200 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Market positioning	Home & office
