246
VB-R13
The camera does not have a power swit
ch. To turn the camera on or off, connect or disc
onnect the power cable.
The LED will flash.
When the LED stops flas
hing, the reset procedure is comple
te.
Reset Switch
LED
Reboot Switch
VB-H651V
1
Turn the camera off.
2
Hold down the reset switch and
connect the power cable. Continue to hold the reset switch for five seconds or
longer.
3
Release the re
set switch.
Reset Switch
LED
245
247
