Preparations 27
To attach an optional shoulder strap
Pass the ends of the shoulder strap through the strap mount on the grip
belt and adjust the length of the strap.
Adjusting the LCD Screen and Using the Viewfinder
Rotating the LCD Panel
Open the LCD panel 90 degrees.
• You can rotate the panel 90 degrees downward.
• You can rotate the panel 180 degrees toward the lens. Rotating the
LCD panel 180 degrees can be useful in the following cases:
- To allow the subject to monitor the LCD screen while you use the
viewfinder.
- To include yourself in the picture when recording with the self timer.
- To allow the camcorder to be operated with the wireless controller
from the front.
180°
90°
Subject can monitor the LCD screen
(You can use the viewfinder at the
same time)
180°
To Next Page
