Preparing the Camcorder
24
Preparing the Camcorder
This section covers the basic preparations for the camcorder such as attaching the handle unit and
lens hood, and adjusting the viewfinder and OLED screen. When attaching the lens hood, grip belt and
straps, be careful not to drop the camcorder by placing it on a table or other stable surface.
Attaching the Microphone Holder Unit
Use the supplied screws to attach the microphone holder unit to
the handle unit.
Attaching the Handle Unit
1 Align the handle unit with the handle attachment unit
and then slide the handle unit forward until it is in place.
• Make sure the front and rear screws are raised when you
slide the handle unit.
2 Firmly tighten the front and rear screws with a coin or
similar object.
NOTES
• The camcorder is functional even if you remove the handle
unit. However, some audio options (A 79), the infrared light
and tally lamp will not be available.
