Canon ZR800 User Manual

Connecting to a TV or VCR
External Connections
43
Playback on a TV Screen
The quality of the playback picture will
vary depending on the connected TV and
the type of connection used.
Before making the connections, select the
[TV TYPE] setting according to the TV set
to which you will connect the camcorder
(29).
Connecting
Connect the camcorder to the TV
following one of the connection diagrams
shown in the previous section Connection
Diagrams ( 42).
Playback
1 Turn on the camcorder and the
connected TV or VCR.
On a TV: Set the input selector to
VIDEO. On a VCR: Set the input
selector to LINE (IN).
2 Start the playback of the movies
( 25).
NOTES
Turn off all the devices before starting the
connections.
We recommend powering the camcorder
using the compact power adapter.
Recording to a VCR or Digital Video
Recorder
You can copy your recordings by
connecting the camcorder to a VCR or a
digital video device. When recording to a
digital video recorder using the DV
terminal, you can copy recordings with
virtually no generation loss in video and
sound quality.
Connect the camcorder to the external
device following one of the connection
diagrams shown in the previous section
Connection Diagrams (42).
Connecting
Connect the camcorder to a VCR or other
analog device using connection type ,
or to a DVD recorder or other digital
recording device using connection type
, as shown in the previous section
Connection Diagrams ( 42).
Recording
1 This camcorder: Load the recorded
cassette.
2 Connected device: Load a blank
cassette or disc and set the device
to record pause mode.
3 This camcorder: Locate the scene
you wish to copy and pause the
playback shortly before the scene.
4 This camcorder: Resume the movie
playback.
When using an analog connection you
can include in the copy also the date/
time of the original recording ( 39).
5 Connected device: Begin recording
when the scene you wish to copy
appears. Stop recording when
copying is complete.
6 This camcorder: Stop playback.
NOTES
We recommend powering the camcorder
using the compact power adapter.
When recording to a VCR using an analog
connection –connection type ( 42)–, the
quality of the edited tape will be lower than the
original.
(9)
(9)
1
2
1

Canon ZR800 Specifications

General

Sensor type	CCD
Total megapixels	0.68 MP
Optical sensor size	1/6 \
Digital zoom	- x
Optical zoom	35 x
Image stabilizer	Yes
Interchangeable lens	-
Camcorder tape type	Mini-DV
Camcorder media type	Videotape
Disc types supported	No
Compatible memory cards	Not supported
Internal storage capacity	- GB
Display diagonal	2.7 \
Viewfinder type	Electronic
Viewfinder resolution	114000 pixels
Viewfinder screen size	0.35 \
Camcorder type	Handheld camcorder
Minimum illumination	2 lx
Supported aspect ratios	4:3, 16:9
Product color	Blue, Silver
Maximum video resolution	- pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery capacity	- mAh
Battery life (max)	- h

Weight and Dimensions

Depth	1190 mm
Width	570 mm
Height	920 mm
Weight	375 g
