Canon ZR800 User Manual

60
General Information
ZR800
Specifications
System
Video Recording System 2 rotary heads, helical scanning DV system (consumer digital VCR SD
system), digital component recording
Audio Recording System PCM digital sound: 16 bit (48 kHz/2 channels); 12 bit (32 kHz)
Television System EIA standard (525 lines, 60 fields) NTSC color signal
Image Sensor 1/6-inch CCD, approx. 680,000 pixels
Effective pixels
16:9 Movies (Image stabilizer [ON]) approx. 360,000 pixels
16:9 Movies (Image stabilizer [OFF]) approx. 450,000 pixels
4:3 Movies approx. 340,000 pixels
Compatible Tapes Videocassettes bearing the mark
Tape Speed SP: 18.81 mm/s (0.74 ips); LP: 12.56 mm/s (0.49 ips)
Maximum Recording Time
(60 min. tape)
SP: 60 minutes; LP: 90 minutes
LCD Screen 2.7 in., wide, TFT color, approx. 112,000 pixels
Viewfinder 0.35 in., wide, TFT color, approx. 114,000 pixels
Microphone Stereo electret condenser microphone
Lens f=2.6–91 mm, F/2.0–5.0, 35x power zoom
35 mm equivalent:
16:9 Movies (Image stabilizer [ON]) 45.8–1,603
16:9 Movies (Image stabilizer [OFF]) 41.0–1,435
4:3 Movies 49.8–1,743
Lens Configuration 10 elements in 8 groups
AF system TTL autofocus, manual focus available
Minimum Focusing Distance 1 m (3.3 ft.); 1 cm (0.39 in.) on maximum wide angle
White Balance Auto white balance, preset white balance (DAYLIGHT, TUNGSTEN) or
custom white balance
Minimum Illumination 2 lx ([NIGHT] recording program, Shutter speed at 1/8)
8 lx (Easy recording mode, Auto slow shutter [ON], Shutter speed at 1/30)
Recommended Illumination More than 100 lx
Image Stabilization Electronic
Input/Output Terminals
AV Terminal ∅3.5 mm minijack, output only
Video: 1 Vp-p/75 ohms unbalanced
Audio: -10 dBV (47 kohms load/3 kohms or less)
DV Terminal 4 pin (IEEE1394 standard), input/output
MIC Terminal ∅3.5 mm stereo mini-jack
–57 dBV (with 600 ohm mic)/5 kohms or more
Power/Others
Power supply (rated) 7.4 V DC (battery pack), 8.4 V DC (compact power adapter)
Power consumption
(AF on)
2.1 W
Operating temperature 0 – 40 °C (32 – 104 °F)
Dimensions (W x H x D) 57 x 92 x 119 mm (2.2 x 3.6 x 4.7 in.) excluding the grip belt
Weight (camcorder body only) 375 g (13.2 oz.)

Canon ZR800 Specifications

General

Sensor type	CCD
Total megapixels	0.68 MP
Optical sensor size	1/6 \
Digital zoom	- x
Optical zoom	35 x
Image stabilizer	Yes
Interchangeable lens	-
Camcorder tape type	Mini-DV
Camcorder media type	Videotape
Disc types supported	No
Compatible memory cards	Not supported
Internal storage capacity	- GB
Display diagonal	2.7 \
Viewfinder type	Electronic
Viewfinder resolution	114000 pixels
Viewfinder screen size	0.35 \
Camcorder type	Handheld camcorder
Minimum illumination	2 lx
Supported aspect ratios	4:3, 16:9
Product color	Blue, Silver
Maximum video resolution	- pixels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery capacity	- mAh
Battery life (max)	- h

Weight and Dimensions

Depth	1190 mm
Width	570 mm
Height	920 mm
Weight	375 g
