Canyon Pedelec - Components Overview; Bicycle Components; Electric Drive Components; Handlebar Components

TABLE OF CONTENTS
2 Notes on this translation of the original operating instructions
5 Intended use
9 Before your rst ride
14 Before every ride
18 Notes on the assembly from the BikeGuard
21 Removing and installing the battery
22 KIOX display
23 Adjusting the integrated brake levers
24 Seat clamping – PRECEDE:ON
25 Gear system enviolo AUTOMATiQ
26 Removing the rear wheel
27 Mounting the rear wheel
28 Calibrating enviolo AUTOMATiQ
28 Checking the belt tension
29 Sliding dropouts – adjusting the tension
30 Riding the pedelec
30 Riding with drive assistance
32 Range – Useful information for a long ride
33 Riding without drive assistance
34 Proper handling of the rechargeable battery
37 Switching the lighting system on
38 Orientation of the front light
39 Croozer child trailer
40 Transport of the pedelec
40 By car
41 By train / By public transport
41 By plane
42 Aer an accident
45 General notes on care and inspection
45 Washing and cleaning your pedelec
47 Servicing and inspection
COMPONENTS
Bicycle components
1 Frame:
a Top tube
b Down tube
c Seat tube
d Chainstay
e Rear stay
f Rear shock
2 Saddle
3 Seat post
4 Seat post clamp
5 Rear brake
6 Cassette sprockets
7 Rear derailleur
8 Chain
9 Chainring
10 Crank set
11 Pedal
Handlebar:
12 Brake lever front/rear
13 Shi lever
14 Control lever
height-adjustable seat post
15 Stem
16 Headset
17 Suspension fork:
I Fork crown
II Stanchion tube
III Lower leg
IV Dropout
18 Front brake
19 Rotor
Wheel:
20 Quick-release/thru axle
21 Rim
22 Spoke
23 Tyre
24 Hub
Electric drive components
A Mid-mounted motor
B Rechargeable battery
C Display
D Control unit
This symbol indicates an imminent risk
to your life or health unless you comply
with the instructions given or take preventive
measures.
This symbol signies information about
how to handle the product or refers to a
passage in the translation of the original oper-
ating instructions that deserves your special
attention.
This symbol warns you about actions
that could lead to damage to property or
the environment.
Note that the aforementioned consequences will
not be repeated each time the symbols appear in
the translation of the original operating instruc-
tions!
NOTES ON THIS TRANSLATION OF THE ORIGINAL OPERATING INSTRUCTIONS
PAY PARTICULAR ATTENTION TO THE FOLLOWING SYMBOLS:
Be sure to read the comprehensive world-specic Canyon bicycle manual MTB, Road or Urban
as well as the system instructions of the drive manufacturer. You can nd these under
www.canyon.com/downloads (as of November2020).
Attention! Assembly instructions in the Quick Start Guide, which comes attached to the
pedelec. You can also nd the Quick Start Guide on our website, www.canyon.com
Read pages 2 to 13 of this manual before your first ride. Perform the functional check on
pages 14 to 17 of this manual before every ride!
