Capacity of Texas, Inc.
100
9 3 Open circuit at release solenoid
9 4 Open circuit in common line to valve
9 5 Short between hold solenoid and supply voltage
9 6 Short between hold solenoid and ground
9 7 Open circuit at hold solenoid
9 8 Valve found wired in wrong location
10 1 Short between release solenoid and supply voltage
10 2 Short between release solenoid and ground
10 3 Open circuit at release solenoid
10 4 Open circuit in common line to valve
10 5 Short between hold solenoid and supply voltage
10 6 Short between hold solenoid and ground
10 7 Open circuit at hold solenoid
10 8 Valve found wired in wrong location
10 10 Diagonal 1 (common side of valves SR.LR.LRR)
shorted to bat
10 11 Diagonal 1 (common side of valves SR.LR.LRR)
shorted to ground
11 1 Short between release solenoid and supply voltage
11 2 Short between release solenoid and ground
11 3 Open circuit at release solenoid
11 4 Open circuit in common line to valve
11 5 Short between hold solenoid and supply voltage
11 6 Short between hold solenoid and ground
11 7 Open circuit at hold solenoid
11 8 Valve found wired in wrong location
11 10 Diagonal 2 (common side of valves SR.LR.LRR)
shorted to bat
11 11 Diagonal 2 (common side of valves SR.LR.LRR)
shorted to ground
12 1 Short between release solenoid and supply voltage
12 2 Short between release solenoid and ground
12 3 Open circuit at release solenoid
12 4 Open circuit in common line to valve
12 5 Short between hold solenoid and supply voltage
12 6 Short between hold solenoid and ground
12 7 Open circuit at hold solenoid
12 8 Valve found wired in wrong location
13 1 Short between release solenoid and supply voltage
13 2 Short between release solenoid and ground
13 3 Open circuit at release solenoid
Table 4-5 ABS Diagnostic Codes (Cont.)
Digit 1 Digit 2 Description
