Capacity of Texas, Inc.
14
Table 2-2 Dash LED Indicators
Item Name Description
1 Left Turn Indicator
Light
Flashing light indicates left turn signal is
operating.
2 Spare Position not used.
3 PTO Light Indicates PTO is engaged
4 Low Air Warning Light Illuminates to warn when air system
pressure drops below 60 PSI. Buzzer will
also sound.
5 Alternator Light Illuminates when the alternator is not
charging battery; battery is being
discharged.
6 Low Fuel Light Illuminates to indicate low fuel level.
7 Spare Position not used.
8 High Beam Light Illuminates when headlights are on high
beam
9 ABS Warning Light Illuminates when a fault with the antilock
brake system (ABS) system is detected.
10 Trailer ABS Warning
Light
Illuminates when a fault with the trailer’s
ABS system is detected.
11 ATC Warning Light Illuminates when a fault with the automatic
traction control (ATC) system is detected.
12 Stop Engine Warning
Light
Illuminates when conditions exist that
could seriously damage the engine.
Operator should turn the engine off
immediately.
13 Engine Warning Light Illuminates when one or more of the
following conditions exist: Low Oil
Pressure, Engine Coolant Overheating,
Low Coolant Level
14 Regeneration Needed
Light
Illuminates to indicate that the engine
requires a regeneration cycle. Refer to
XREF for more information.
15 Wait To Start Light Illuminates to indicate operator should not
start engine until engine grid heaters are
heating for a specific time prior to ignition.
16 Check Transmission
Light
Illuminates when a fault with the
transmission has been detected. Refer to
XREF for more information.
17 Spare Position not used.
18 Fifth Wheel Lock Light Illuminates when fifth wheel is locked.
