Capital MCOR304 - Oven Parts Identification

12
OVEN RANGE PART IDENTIFICATION
MCOR -SERIES
1.Large Oven
2.Oven Thermostat Sensing Bulb
3.Convection Baffle
4.Convection Fan (center back
wall of oven can behind baffle)
5.Oven Light
6.Broiler Burner
7.Oven Fan Switch
8.Oven Light Switch
9.Small Oven
10.Oven Gasket
8
7
