20 Instruction manual CAFF46GM Please keep this instruction manual for future reference
DISPLAY AND CONTROL PANEL
1. Fridge compartment
temperature indicator
2. Left freezer compartment
temperature indicator
3. Right freezer compartment temperature
4. Super Cool mode light
5. Super Freeze mode light
6. QDrink alarm timer
7. QDrink alarm light
8. Economy mode
9. Holiday mode
10. Night Sensor
11. Child lock
12. Dealer Demo mode
13. Low voltage warning
14. Alarm
15. Screensaver button
16. Zone 2 (right freezer) button
17. Mode button
18. Cooler button
19. Qdrink mode button
20. Zone 1 (left freezer) button
DISPLAY AND CONTROL PANEL
1. Fridge compartment temperature indicator
2. Left freezer compartment temperature indicator
3. Right freezer compartment temperature
4. Super Cool mode light
5. Super Freeze mode light
6. QDrink alarm timer
7. QDrink alarm light
8. Economy mode
9. Holiday mode
10. Night Sensor
11. Child lock
12. Dealer Demo mode
13. Low voltage warning
14. Alarm
15. Screensaver button
16. Zone 2 (right freezer) button
17. Mode button
18. Cooler button
19. Qdrink mode button
20. Zone 1 (left freezer) button
The values on the screen indicate temperature values specified by the consumer.
The Standby display is protected against faulty contact. Therefore, you must touch any key
on the display before you make an action. After 2 seconds, a beep will sound and the
display will be ready for use. Wait 20 seconds at the end of the process and the display will
return to Standby mode.
1 19 20 2101817 3 16 15
547
6
8
9
11
12
13
14
The values on the screen indicate temperature values specified by the consumer.
The Standby display is protected against faulty contact. Therefore, you must touch any key
on the display before you make an action. After 2 seconds, a beep will sound and the display
will be ready for use. Wait 20 seconds at the end of the process and the display will return to
Standby mode.
