Instruction manual FGC621 FGC721 FGC921 11
Please keep this instruction manual for future reference
INSTALLATION - DUCTED
WARNING:
Observe the warning concerning the operation of the appliance when air is discharged from
the room.
When the cooker hood and appliance supplied with energy other than electricity are
simultaneously in operation, the negative pressure in the room must not exceed 4 Pa (4×10
-5
Bar).
Drill 3 x 8mm holes to accommodate the bracket. Screw and tighten the bracket onto the wall with
the screws and screw plugs provided.
Level up the cooker hood and hang onto the wall bracket hook.
5
5
Screw Plug
Wall Bracket
Holes on Wall
Screw
(4mm x 30mm)
Wall Bracket
Cooker Hood
To Next Page
