Caple WF1552 - How to Replace the Charcoal Filter

16 Instruction manual WF1552 & WF1553 Please keep this instruction manual for future reference
HOW TO REPLACE THE CHARCOAL FILTER
Charcoal filters are located in the top left corner of each wine cabinet zone.
1. Open the door and remove the top 2 shelves (see removing the shelves).
2. Turn the filter as per Fig A.
3. As per Fig B, the filter should line up with the notches as shown.
4. Pull the filter out (Fig C).
5. Insert replacement filter and twist as per Fig A to lock into position.
6. Re-install the shelves.
