Capresso CoffeeTEC 471 - Line Drawings (Figures 1-14)

A. Water Container Lid
B. Sticker: Capresso Plus Service
C. Water Container (removable)
D. Display and Operating Panel
(see figure 2)
E. Milk Container with Lid
F. Drip Grid
G. Drip Tray
H. Platform
I. Stainless Steel Carafe with Lid
J. Swing-Out Filter
K. Push Button for Swing-Out Filter
L. LCD Display
M. On Light (red)
N. Auto Light (green)
O. 3-5 cup Light (green)
P. On/Off Button with Knob for 3-5 cup Setting
and Auto Setting
Q. Program Light (green)
R. Steam Ready Light (green)
S. Program Button with Knob for Hour and Minute
Setting
T. Steam Selector
U. Steam Nozzle
V. Connector
W. Frothing Sleeve
X. Knob (for regulating froth)
Y. Joint
Z. Milk Container Lid with Siphoning Straw
FIG. 2
FIG. 3
FIG. 1
H
I
J
K
L
O
P
U
V
W
X
Y
Z
Q
R
S
T
M
N
5
